BAL-1200 (IMPA 330638): ATEX Explosion Proof Air Turbo Lamp Halogen Bulb 24V 250W Bay light

The ATEX Air Turbo Light BAL-1200 is an aluminum ultra-light lamp with a high-power compressed air drive used in potentially explosive atmospheres.

It provides illumination for shot-blasting, cleaning, and coating storage tanks, vessels, pipelines, and structural engineering activities. It offers a safer alternative to mains and low-voltage lighting, as the explosive atmospheres pose a severe risk to the workforce.

It uses a 250-watt Halogen lamp, which offers brilliant warm white output, high reliability, and low maintenance. This light source provides high-quality ambient lighting.

This air turbo light is also RoHS and CE certified.

*Tripod stand sold separately.

Ex Mark:
II 2G Ex eb pxb IIC T6 Gb
II 2D Ex tb IIIC T85°C Db

• Chinese Design Patent No.: 201330638092.2
• Type of Protection:
  • "eb" Increased Safety
  • "pxb" Pressurised
  • "tb" Dust Ignition Protection by Enclosure
• Areas of Classification (Gases): Zone 1 and 2, Gas Groups: IIA, IIB, and IIC
• Areas of Classification (Dusts): Zone 21 and 22, Dust Groups: IIIA, IIIB, and IIIC
• Temperature Classification (Gases / Dusts): T6 / 85°C
• Enclosure: Impact-Resistant Thermoplastic, Antistatic
• Beam Type: Bay Light
• Color Temperature: 3,200K
• Output: 7,500 Lumens (effective lumens)
• Light Source Type: Halogen Lamp
• Voltage / Watts: 24V / 250W
• Area: Oil & Petrochemicals Industries
• Working Pressure: 4.0-8.0 Bar
• Inlet Air Supply Hose: Antistatic Hose, Φ12mm (inner diameter)
• Product Net Weight: 5.55kg
• Dimension: Φ152*295mm
• Packing: 1 piece per carton, size: 34*24*28cm
